PU Foaming Galvanized Steel Overhead Garage Door IP55 With Windows

China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
I'm Online Chat Now

PU Foaming Galvanized Steel Overhead Garage Door IP55 With Windows

PU Foaming Galvanized Steel Overhead Garage Door IP55 With Windows
PU Foaming Galvanized Steel Overhead Garage Door IP55 With Windows
video play

Large Image :  PU Foaming Galvanized Steel Overhead Garage Door IP55 With Windows

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: SOSGD-0031
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
Material: Aluminum Or Galvanized Steel Foaming Material: Polyurethane
Foaming Process: Automatically Color: White,Cream, Wooden Grain,Bronze Or Customized
Opening: Roll Up Opening Way: Electric,Manual,Remote Control
OEM: Acceptable Size: Customized
Thickness Of Aluminum: 40mm/Custom Width Of Panel: 500mm/Custom
Application: Residential/Hotel/Office Building/Shop/Villa/etc Feature: High Durability/Heat Preservation/Thermal Insulation
Position: Garage Protection Class: IP55
Door Panel Pattern: Linear Door Panel Design: Finger-Protection Design
Bracket Thickness: 3.0mm Surface Finishing: Finished
Panel Width: 430-550mm, Adjusted Max Length Of Panel: 12m
Height: 435mm, 485mm, 535mm Or Customized Max Width: Maximum 6500mm
Total Thickness: 38mm Guide Rail Thickness: 2.0mm
Tracks: Single Track Or Double Track Output Torque: 1000N
Export Markets: Global Transport Package: Plywood Case Or Cardboard+pallets, As Your Request.
Handware: With All Handware HS Code: 73083000
High Light:

PU Foaming Overhead Garage Door

,

Overhead Garage Door IP55

,

Sliding Garage Door IP55

Hot Sale Overhead White Garage Door with Windows / Automatic Overhead Sliding Garage Door
Garage door is popular with the pursuit of better life,it has the advantages of convenient operation, strong practicability, space saving, beautiful appearance and so on.
It is a door which is lifted up to overhead,it is generally made of solid wood and metal and widely used in our life for its excellent performances.Anti theft device could be installed in it.The door would stop rolling down if it touches any obstacle to protect people and cars with the anti theft system.
The solid wood door has a characteristic of warmth since ancient times. The wood grain garage door produced by Zhongtai is not only gorgeous and exquisite, but also varies in style with personalized design which could meet the needs of different customers.



Features:

1.The garage door is controlled by microcomputer program, it is easy to use and can be controlled by remote control handle.And the motor has its own automatic delay lighting lamp,of which extension time is 3 to 5 minutes.
2.The garage door operates with super mute which is environmental protection. When the power failure is equipped with an emergency lock, the switch is more easy and convenient.
3.The color of the garage door are bright, beautiful, elegant, concise and generous. Equipped with airbags,it would rebound to prevent and guarantee the safety if the garage door touches any obstacle.
4.The principle of garage door is scientific, the inside torsion spring of the door is equal to the weight of the door so that the door body is in the "zero weight" state. And it runs on the pulley in the track, so the resistance is small, the energy consumption is less and the maintenance rate is low with its strong durability.
5.There is a power outage backup battery working function,it could be opened without manual even after the power failure.



Product Details:

Material Galvanized steel with PU foaming inside
Material Construction Steel-foam-Steel, sandwich panel
Thickness of the steel plate 0.4mm
Thickness of the panel 40mm
Panel length/panel width 2m~12m/500mm
Section Style Finger protection panel
Maximum size Height:6m*Width:8m
Section Surface Finish orange peel, flush
Front-side design with Rectangle/stripes design
Backside design with Stripe/flush design
Accessories Single Track with min headroom for 350mm;
Double Track with min headroom for 150mm
Door motor AC220V or 110V; DC Motor; 800-1500N
Opening Way Electrical control and Manual operation
Color White and other colors can be customized



Why Choose Us?

Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.

Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.



F A Q :


1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
