Stacking 100mm 0.8mm Curtain Garage Roller Shutters

Stacking 100mm 0.8mm Curtain Garage Roller Shutters

Stacking 100mm 0.8mm Curtain Garage Roller Shutters
Stacking 100mm 0.8mm Curtain Garage Roller Shutters Stacking 100mm 0.8mm Curtain Garage Roller Shutters Stacking 100mm 0.8mm Curtain Garage Roller Shutters Stacking 100mm 0.8mm Curtain Garage Roller Shutters

Large Image :  Stacking 100mm 0.8mm Curtain Garage Roller Shutters Get Best Price

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: HSSD-00012
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 500sets per month
Detailed Product Description
Type: Stacking Open Style: Stacking
Opening Type: With Remote Control Special Function: Insect Prevention+Dust Prevention
Color: Yellow,Orange,Red,Grey,Blue,Green Or Customized Position: Industrial,Warehouse,Garage, Exterior, Interior,Room,
Surface Finishing: Finished Motor: German Sew / China Sej / Or Customized
Control Panel: Can Be Optional Command System: Radar Sensor, Magnetic Loop , Remote Control,
Normal Working: -35 To 65 Celsius Degree Standard Motor Position: Left Or Right
Installation Base: Concrete,Panel, Brick,Steel Structure. Safety Device: Photocell Sensor
Door Frame Structure: 2.0 Mm Galvanized Steel / 304 Stainless Sheet Wind Resistance: Class 12
Transport Package: Plywood Case Or Cardboard, As Your Request. Specification: Effective Max Size: W10m X H10 M
Origin: Dongguan, China HS Code: 73083000
High Light:

0.8mm Curtain garage roller shutters

,

100mm garage roller shutters

,

100mm steel roller shutter

Environmental Safety Wind Resistant Stacking PVC Fabric Door Curtain High Speed Door For Workshop / Warehouse



Stacked high speed door is a new generation door that used in large buildings. It has the good windproof function,with the steel tube in side,Which can greatly resist the wind



Features:
This door is with excellent wind-resistant performance, fit for areas with big wind pressure and door hole sizes. Several
high-strength aluminum rod is used to connect PVC fabric as a whole. When faced with big wind, such rods will offer big
support. Special belt structure is adopted to lift door up and down by revolving roller.
The advantage of Self Reparing High Speed Doors are self-reparing,easy to clean,complete safe,energy saving and so on.
If the door curtain comes out of its guides(for example in the event of impact with a forklift),the system will reset the cutrain back intp the guide during the next opening cycle autimatically

Motor System:
Power Supply: 0.75kw, 1.5kw, 2.2kw
The incremental encoder mounted is attached to the end of the drum shaft.

Self-Repairing Door Curtain:
Made of reinforced PVC, with flexible weighted soft bottom edge.
The edge of curtain has continuous injection molded teeth that then move up and down in a self-lubricating polyethylene track attached to structural galvanized side frames.



Opening Way
Forklift cross --Magnetic loop with push button
People cross --Radar sensor with push button
Photocell sensor/Airbag to avoid hurt people when the door closing and someone cross.



Technical Data:

Door curtain Various cladding material for options:
a.Plastic polyester fiber with PVC/PU/Silicone rubber/PolyYaan ester coating
b.Resistance to low temperature curtain for -45ºC environment
c.Soundproof door curtain for environment that need to be reduced or isolated from noise
d.Heat preservation curtain for environment that prevent thermal radiation or chemical damage
e.Safety curtain is for higher environmental safety requirement
Door Keel Aluminum profile installed in the middle of door curtain to strengthen support
Guide Rail Material: Aluminum
Sealing design of the inner and outer surface of guide rail
Thickness of Door 100-160mm
Thickness of Curtain 0.8+0.8mm
Running Speed 0.2~0.3m/s
Running Temperature -35ºC to +70ºC
Driving System Motor and gearbox,220V/380V 50Hz, power:1.6-3.7kW
Control System Control box with PLC:The running of the door can be achieved by pressing the button on the control box or using the radar or magnet ring control with optional controls
Optional Control Radar,magnet ring,remote control,stretching wire switch,controller button,Interlocking
Hoisting System The lifting belt around the pulley is connected with the safety clamp along the vertical track. The pulley is mounted on the brake reducer.
Waterproof Permeability 3 level, EN12425 (door closed state)
Wind Resistance 3-5 grade,EN 12424 varies according to the size of the door
Air Tightness 2grade,EN12426
Sealing Bottom, side and top seal
Safety Safety Photo Sensor
Proximity Sensor
sound-light alarm system
Accident-fall arrester safety system



Why Choose Us?



Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.

Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.



F A Q :


1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
