PU Foaming Insulated Sectional Garage Doors Residential

PU Foaming Insulated Sectional Garage Doors Residential
PU Foaming Insulated Sectional Garage Doors Residential
video play

Large Image :  PU Foaming Insulated Sectional Garage Doors Residential

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: SOSGD-0035
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
Material: Aluminum Or Galvanized Steel Foaming Material: Polyurethane
Foaming Process: Automatically Color: White,Cream, Wooden Grain,Bronze Or Customized
Opening: Roll Up Opening Way: Electric,Manual,Remote Control
OEM: Acceptable Size: Customized
Thickness Of Aluminum: 40mm/Custom Width Of Panel: 500mm/Custom
Application: Residential/Hotel/Office Building/Shop/Villa/etc Feature: High Durability/Heat Preservation/Thermal Insulation
Position: Garage Protection Class: IP55
Door Panel Pattern: Linear Door Panel Design: Finger-Protection Design
Bracket Thickness: 3.0mm Surface Finishing: Finished
Panel Width: 430-550mm, Adjusted Max Length Of Panel: 12m
Height: 435mm, 485mm, 535mm Or Customized Max Width: Maximum 6500mm
Total Thickness: 38mm Guide Rail Thickness: 2.0mm
Tracks: Single Track Or Double Track Output Torque: 1000N
Export Markets: Global Transport Package: Plywood Case Or Cardboard+pallets, As Your Request.
Handware: With All Handware HS Code: 73083000
High Light:

Residential Insulated Sectional Overhead Doors


4cm Panel Insulated Sectional Garage Doors


PU Foaming Insulated Sectional Garage Doors

Professional Manufacture Insulated Overhead Sectional Garage Door For Morden House


For premium construction and maximum thermal efficiency, a insulated steel garage door is the ideal choice. This series of doors feature our sandwich construction of steel-polyurethane-steel as well as between-section seals with thermal breaks to reduce air infiltration. Durable garage doors that guard against wind and rain and add beauty, sophistication, and durability to your home. Up to lifetime limited warranty available.



Garage Door Panels:
1. 4cm thickness panels.
2. Good appearance color with grain.
3. Warm keeping, light weight.
4. Many color options


High Quality Doorman Opener:
1. One year warranty.
2. CE Certifications.
3. Light for dark environment.
4. Smart and easy installation.
5. Best motor lift-master can be choose.
High Quality Hardware Accessories:
1. 2'' galvanzied hardwares accessories.
2. Waterproof and rust prevention.
3. Materials from BAOSTEEL or ANSTEEL.


Product Description:

Panel Materials: Galvanized Steel with PU, 4cm Thickness Each panel width: 450mm-550mm
Track and hardwares: Galvanized Steel 2 inch
Seals: Perfect quadrilateral sealing as bottom seal
Motor: Power: 110V/220V Frequency :50HZ/60HZ
Operating temperature: -20℃ to 60℃
Max. area: Max Width: 6.5m, max height:3.5m
Wind resistance: 62-74km/h
Opening direction: Sectional, overhead sliding
Operation Manual, Automatic, Remote Control.
Safety System: Anti-fall device, Anti-collision devices
Standard Accessories: Remote control, Emergency lock
Optional Accessories: Bluetooth, Infrared sensor, wall switch, exterior numerical pad



About Us


Established in 2006, HengTaichang Intelligent gate control technology co., LTD is a leading manufacturer of automatic doors. We are located in Dongguan as known as " factory of the world" , . It is very convenient to all over the world by air or sea.
HengTaichang Is a high-tech company that integrates development, design, production, installation, sales,service and after-sales as one of the professional manufacturers, Over the years, we have designed, developed and manufactured a wide range of automatic doors, such as high speed rolling curtain doors, Industrial sliding door, Rapid metal shutter door, rapid accumulation of doors, silent roller shutter door, commerce crystal folding door, Fire Proof & Blast Proof Door, Hard Rapid Turbo Roller Door, remote control sectional garage door, remote roller shutter window and so on.
F A Q :

1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
