| Material: | Galvanized Steel With PU Foaming Inside | Color: | White, Gray, Red, Blue, Natural Or Customized |
|---|---|---|---|
| Construction: | Steel - Foam - Steel Sandwich Construction | Galvanized Steel Thickness: | 0.35mm / 0.45mm / 0.50mm |
| Panel Thickness: | 40mm / 50mm | Panel Height: | 440mm - 550mm, Adjustable |
| Optional Component: | Window & Pedestrian Gate | Panel Width: | 440-550mm, Can Be Adjust |
| Packing Details: | Carton Paper + Pearl Cotton | Door Panel Pattern: | Woodgrain,Orange Peel,Fold,Flush |
| Surface Finishing: | Finished | Open Style: | Automatic |
| Panel Design: | Casstte, Stripe Lines, Fold | Max Available Panel Length: | 11.8m (to Fit The Container) |
| Wind Resistance: | Class 3 | Water Tightness: | Class 3 |
| Noise Level: | 22dB | Insulation Density: | 43-45kg/M³ |
| Foam Insulation Value: | 13.73 | Enterprise Nature: | Manufacturer And Trader Since 2009 |
| Specification: | Customized Size | HS Code: | 73083 |
| High Light: | 600N Industrial Roll Up Doors,50mm Industrial Roll Up Doors,600N industrial sectional door |
||
Product Description:
| Door panels | Panle style | Finger protection/general type |
| Panel construction | Steel+PU Foam+Steel | |
| Panel thickness | 40/50mm | |
| Panel max height | 575mm | |
| Panle color | White,grey,walnut,mahogany,cream,OEM | |
| Panel surface texture | Orang or Wood finished | |
| Panel type | Flat,Stripe,block | |
| Panel steel thickness | 0.376mm/0.476mm | |
| Door Hardwares | Track style | Double track/ Single track |
| Track Thickness | 2.0mm | |
| Track Cover | Available | |
| Track&Track cover surface finished | Bright Zinc Galvanized | |
| Hinges&Roller Brackets thickness | 2.0mm | |
| Bearing Bracket thickness | 2.5mm | |
| Top &Bottom Stretch | Plastic or Aluminum | |
| Top&Side&Bottom Rubber | Included | |
| Safety system | Available | |
| Spring break safety brackets | ||
| available | ||
| Cable break Safety system | ||
| Door Motor | Motor Voltage | 110V or 220V |
| Motor Force | 600N/800N/100N/1200N | |
| Motor lift Height | 2.2m/2.5m/2.8m/3.1m/3.4m | |
| Motor Remote Controls | 2 or more | |
| Motor sensor/Alarming/Wall Brackets/ | Available | |
| Keypad/Back battery | ||
Why Choose Us?
Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.
