Aluminium 2100mm Height Sectional Overhead Garage Door

China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
I'm Online Chat Now

Aluminium 2100mm Height Sectional Overhead Garage Door

Aluminium 2100mm Height Sectional Overhead Garage Door
Aluminium 2100mm Height Sectional Overhead Garage Door
video play

Large Image :  Aluminium 2100mm Height Sectional Overhead Garage Door

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: SOSGD-00013
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: T/T, Western Union, MoneyGram
Detailed Product Description
Material: Aluminum Or Galvanized Steel Foaming Material: Polyurethane
Foaming Process: Automatically Color: White,Cream, Wooden Grain,Bronze Or Customized
Opening: Roll Up Opening Way: Electric,Manual,Remote Control
OEM: Acceptable Size: Customized
Thickness Of Aluminum: 40mm/Custom Width Of Panel: 500mm/Custom
Application: Residential/Hotel/Office Building/Shop/Villa/etc Feature: High Durability/Heat Preservation/Thermal Insulation
Position: Garage Protection Class: IP55
Door Panel Pattern: Linear Door Panel Design: Finger-Protection Design
Bracket Thickness: 3.0mm Surface Finishing: Finished
Panel Width: 430-550mm, Adjusted Max Length Of Panel: 12m
Height: 435mm, 485mm, 535mm Or Customized Max Width: Maximum 6500mm
Total Thickness: 38mm Guide Rail Thickness: 2.0mm
Tracks: Single Track Or Double Track Output Torque: 1000N
Export Markets: Global Transport Package: Plywood Case Or Cardboard+pallets, As Your Request.
Handware: With All Handware HS Code: 73083000
High Light:

2100mm height Sectional Overhead Garage Door


Aluminium Sectional Overhead Garage Door


2100mm height steel sectional garage doors

Modern Aluminium Panels Garage Door Design Automatic Sensing Aluminum Tilt Panel Lift Single Garage Doors


The density of the sectional garage door panel is 40kg/m3,which could offer high thermal efficiency and sound insulation to your garage .
The thickness is 40mm,which make the garage door panel has excellent mechanical properties, the size is stable, even under low temperature the panels' strength will not change; the panels' long-term heat resistance temperatures are between -50ºC-+100ºC .
The External skins of our panel are PPGI steel which resist rust, and the stability of their painting colors meeting 25 -30 years using life
There are three kinds of surface texture : Wood grain, orange peel, and smooth.

New bottom bracket which could keep the bottom roller in its position ,never drop off. More convenience which it could bring us is the tightness of the cables could be adjusted easily by the bracket.
Besides the above mentioned , once the cable was loose the customer could adjust it by the bracket easily, it will save the cost of the after-sales service a lot.



The door panel adopts the superior color coating steel plate which has been press into elegant decorative patterns.
The external part has been treated with painting.
The internal filler of PU foamed staff make the door panel sound proof, heat proof and enough intensity.
B, Aluminum alloy sectional garage door panel
Material :
1, 1.2mm aluminum + 4mm tempered glass or 4mm Acrylic panel .
2, Aluminum panel
Panel width: 1800mm ---5000mm Door width: 1800mm ---5000mm
Panel Height: 400mm—600mm/pc Door height : 2100mm---6000mm
The hardware parts utilize the heat zinc-plated steel plate for the stamping and manufacture. The perfect balancing system promise the door fine balancing condition.
Material: Galvanized Steel
Hardware color: galvanized color or painted white .
Different motor power for different size garage doors. (600N ,800N,1000N, 1200N,1500N ,1800N)


Product Details:


Material double steel plate, aluminum plate or stainless steel plate
Interface mode Anti-clamping hand interface, no seams between the door body, no safety hazards. Dustproof and Rainproof.
Surface treatment: The surface is embossed wood texture, three-dimensional grid with decorative, strong three-dimensional feeling, generous, practical.
Thickness total thickness 40-50mm.
Color providing a variety of colors for customers to choose, or according to the color card provided by the customer to produce
Sealing device High quality rubber, built-in wool bar or outer PVC sealing device.
Balancing system Using a torsion spring or tension spring balance system.
Hardware accessories Use galvanized or galvanized to spray plastic hardware accessories.
Opening method button, remote control, sensor, bluetooth, etc.
Safety device Marked with resistance rebound function,it can automatically rebound or stop when the door body touches the obstacle.
Optional configuration Windows, The door on the door, infrared protection device, anti-breaking device.

About Us


Established in 2006, HengTaichang Intelligent gate control technology co., LTD is a leading manufacturer of automatic doors. We are located in Dongguan as known as " factory of the world" , . It is very convenient to all over the world by air or sea.
HengTaichang Is a high-tech company that integrates development, design, production, installation, sales,service and after-sales as one of the professional manufacturers, Over the years, we have designed, developed and manufactured a wide range of automatic doors, such as high speed rolling curtain doors, Industrial sliding door, Rapid metal shutter door, rapid accumulation of doors, silent roller shutter door, commerce crystal folding door, Fire Proof & Blast Proof Door, Hard Rapid Turbo Roller Door, remote control sectional garage door, remote roller shutter window and so on.


F A Q :

1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
