Width 2000mm 1.5 M/S High Speed Spiral Door For Warehouse

China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
I'm Online Chat Now

Width 2000mm 1.5 M/S High Speed Spiral Door For Warehouse

Width 2000mm 1.5 M/S High Speed Spiral Door For Warehouse
Width 2000mm 1.5 M/S High Speed Spiral Door For Warehouse
video play

Large Image :  Width 2000mm 1.5 M/S High Speed Spiral Door For Warehouse

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: SD00019
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1950-4850 per set
Packaging Details: wood case or strong paper carton
Delivery Time: 8 -15days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 300pcs per month
Detailed Product Description
Material: Galvanized Steel / Stainless Steel Color: Red, Blue, Green, Yellow, Orange, Gray, Black, White, Natural (customizable)
Opening Speed: 0.6m/s-1.2/s (adjustable) Applications: Garage, Supermarkets, Hypermarkets, Warehouses, Loading Docks, Platforms, Laboratories And Pavilions Etc. And Other Quick Passages.
Guide: Double Spiral Turbo Aluminum Rails, Door Rises When No Contact Between The Door And The Connecting Part. Door Frame: Enviromental Quality CNC Bending Galvanized Sheet Molding Thickness 2mm, External Appearance And Dustproof.
The Ways Of Operation: Radar, Geomagnetic Sensor, Bluetooth, Remote Control,manually Switch, Push Button. Wind Resistance: ≤ Grade 12
Filling Material: Polyurethane Foam Power Supply: 1-Phase 220V, Or 3-Phase 380V
Opening Speed: 2.5m/S Max Applicable Area: Both External And Internal
Surface Finishing: Finished Closing Speedt: 1.2m/S Max
Operation: Control Button, Remote Control Or Sensors HS Code: 853080000
High Light:

1.5 m/s High Speed Spiral Door


Width 2000mm High Speed Spiral Door


Width 2000mm fast roll up door

Industrial Fast Spiral Door High Speed Shutter Door for Food Factory, Warehouse, Clean Room, Pharmaceutical


Fast spiral door can be used for various indoor / outdoor space separation and high-speed and frequent use of ordinary manufacturing or logistics facilities.
It has very good wind resistance, compact structure, simple / delicate appearance, superior performance, small occupation space, flexible control and other advantages. It is applicable to any general manufacturing and industrial logistics area with high wind pressure load and high insulation requirements.
It can improve the efficiency of indoor air conditioning. Control the mixing of foreign matters in the outdoor to minimize the working efficiency. Realize safe, clean and energy-saving working environment, improve product quality and reduce cost.



1, Carefully select material
using 1.2mm/1.5mm/2.0mm aluminium alloy plate which ensure this door meet customer's need.

2, Apeture diaphragm design
This kind of safely device is built into frame,it will feel object within it area. It will stop instantly when someone go through the door

3, Fast and noiseless
With spiral round non-contact track, this sectional curtain will connect each other when door roll up, the curtain material won't wear out and distort, it run fast without noise.

4, Isolating function
The panel is built into sealing which don't allow the air water, dust pest or other contaminants go into space after the door is shutter

Technical Specifications

NO. Item Index
1 Size ranges Width 2000mm~6000mm; Height 2000mm~6000mm
2 Open control ways controled by control box--Control Options: radar, geomagnetic sensor, Bluetooth RF sensor, remote sensing, pull rope switches and other control methods
3 Drive system German SEW motor, Holip Inverter, Kewei plc (Mitsubishi technology)
4 Heat preservation performance at least be K ≤ 1.7W/ (m2K)
5 Air tightness 8.68m3 / (m2 h), reached the national standard grade 3
6 Water tightness ≤700Pa, which reached the national standard grade 6
7 Color optional grey, aluminum primary color, white, red, beige, etc.
8 Opening and closing speed Opening speed:0.8 ~ 1.5 m/s (adjustable);
Closing speed: ≥ 0.6m/s, (adjustable)
9 Wind resistance 3.5 k Pa, reached grade 6 of the GB; Wind resistance grade 12 (120km/h)


Why Choose Us?

Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.

Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.


Curtain material: high-strength industrial aluminum alloy material rolled sheet

Appearance: Electrostatic spraying of galvanized sheet frame or cold rolled sheet.

Switch mode: standard button control.

Balance system: Standard balance system keeps the curtain vertical and opens smoothly.

Safety system: built-in safety fuse and safety switch,automatic safety bottom and safety electric,emergency open manually.

Optional configuration: radal control, geomagnetic control, manual drawstring control, remote control, double- side button.

Control method: frequency conversion control box

Opening speed: up to 2.5m/s, adjustable

Motor power: 1.5kw-2.2kw

Control power: 380V

Sealing performance: rail seal,curtain connection seal

Manual fuction: Contains manual emergency device


F A Q :

1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
