Product Details:
Payment & Shipping Terms:
|
| Material: | Galvanized Steel / Stainless Steel | Color: | Red, Blue, Green, Yellow, Orange, Gray, Black, White, Natural (customizable) |
|---|---|---|---|
| Opening Speed: | 0.6m/s-1.2/s (adjustable) | Applications: | Garage, Supermarkets, Hypermarkets, Warehouses, Loading Docks, Platforms, Laboratories And Pavilions Etc. And Other Quick Passages. |
| Guide: | Double Spiral Turbo Aluminum Rails, Door Rises When No Contact Between The Door And The Connecting Part. | Door Frame: | Enviromental Quality CNC Bending Galvanized Sheet Molding Thickness 2mm, External Appearance And Dustproof. |
| The Ways Of Operation: | Radar, Geomagnetic Sensor, Bluetooth, Remote Control,manually Switch, Push Button. | Wind Resistance: | ≤ Grade 12 |
| Filling Material: | Polyurethane Foam | Power Supply: | 1-Phase 220V, Or 3-Phase 380V |
| Opening Speed: | 2.5m/S Max | Applicable Area: | Both External And Internal |
| Surface Finishing: | Finished | Closing Speedt: | 1.2m/S Max |
| Operation: | Control Button, Remote Control Or Sensors | HS Code: | 853080000 |
| High Light: | 2.2m/S High Speed Spiral Door,220V High Speed Spiral Door,2.2m/S high speed industrial doors |
||
Fire Proof Fire Station Used High Speed Spiral Door / Rapid Aluminum Alloy Rolling Fire Rate Door
High Speed Door is widely used in modern factories and warehouses. It can run in very high speed (up to 2.5m/s)and frequency (up to 2000 times/day), very fit for areas with heavy traffic. Air flow through the door is reduced obviously, to protect indoor environment. Automatic running is realized with programmed control system and sensors.
Aluminum Spiral High Speed Doors. A model of Rapid Doors with thermal insulated aluminum slats. Most advanced and high-oriented model. It is fit for areas with high demand of both security, high-strength, thermal insulation and high running speed.
Feature:
1, Fast and Non Friction
With spiral round non-contact track, the sectional curtains won’t connect with each other when roll up,the curtain material won’t wear, distort and run fast without noise which provide a long using life during the high cycles every day operation.
2, PU foam filled with Panel
3,Lifting system
Specification:
| Door frame componet | door frame,door panel,rubber sealing strip,hinge,and Polyurethane (pu) material fill in door panel |
| Size of door | 4200mm width 4500mm Height or customized |
| Color | Choose grey or customized another color |
| Opening and closed speed | 1.2 -2.35m/s(adjustable openning),0.6m/s(adjustable closed) |
| Control system | Special servo system |
| Drive motor | German brand servo motor or China brand motor or customized |
| Safety device | buffer device at the bottom of door to in sure of the safety |
| Structure of Door | five type ,Elliptical helical structure ,complex called Elliptical helical structure,L shape structure. vertical structure and horizontal structure. |
