Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd.
Home ProductsPVC Roller Shutter Doors

Fast Rolling IP55 Safety DC24V Speed Shutter Door

China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
I'm Online Chat Now

Fast Rolling IP55 Safety DC24V Speed Shutter Door

Fast Rolling IP55 Safety DC24V Speed Shutter Door
Fast Rolling IP55 Safety DC24V Speed Shutter Door
video play

Large Image :  Fast Rolling IP55 Safety DC24V Speed Shutter Door

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: PHSD-00022
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: L/C, Western Union, MoneyGram
Supply Ability: 300pcs per month
Detailed Product Description
Material: PVC Fabric Door Frame Material: Stainless Steel / Aluminum Alloy / Power Coated Steel
Color: Blue, Black, WHITE, RED, Yellow, Orange, SKY BLUE, Light Grey Or Customized Pecial Door Type: Automatic Door
Open Style: Rolling Opening Speed: 0.7~1.2m/S
Curtain Thickness: 0.8mm/1.5mm Opening Style: Automatic & Manual
Operation Way: Push Button / Sensor / Radar / Pull Switch Opening Frequency: 1000-1500times/Day
Opening Type: Power Driven Special Function: Dust Proof, Security
Motor: 1.German Sew 2.China Sej / Snma Or Customized Motor Power: 0.75-5.5kw
Standard Motor Position: Left Or Right Application: Mall, Supermarket, Warehouse, Workshop
Type: Entry Doors,Garage Doors,Security Doors,Sliding Doors,industrial Door Size: Customized Size, According To Clients' Specification
Wind Resistence: 25m/S Specification: Maximun Size 6m*6m
Working Temperature: -35 To 65 Celsius Degree Installation Area: Exterior Or Interior
Safety Class: IP55 Emergency Operation: Available With Manual Crank
Operating Life: 50,000 Cycles Operation Switch: Button Switch, Radar Sensor, Magnetic Loop
High Light:

IP55 Safety speed shutter door

,

DC24V speed shutter door

,

DC24V automatic security shutters

Logistics PVC Fast Rolling Prices Industrial Rapid Roll up Door High Speed Shutter Doors



HengTaichang PVC high speed roller shutter doors are designed for fast open and close, allowing people and/or equipment to move quickly through the opening. This type of doors is ideal for large size opening and designed for high performance daily use both internally and externally with minimal maintenance. The door operated as speed > 1m/s, this model doors offers beneficial energy saving in both commercial and industrial application. In additional it reduces noise and dust from nearby working areas. It was ideally choice for many commercial and industrial application



Features:

1.Multiple functions:it has the functions of thermal insulation, insect proof, noise reduction, smell insulation, indoor barrier effect,reducing energy consumption and keeping the cleanness of indoor working environment .
2.Strong sealing performance: its composite material guide can be closed enough with door frame under the wind pressure. The bottom of the door frame is equipped with aggravated septum ,it can be closely attached to uneven ground to ensure its leakproofness.
3.Various designs :its size can be adjusted according to the size of the installation site, and windows can be added to increase indoor lighting and transparency.
4.Safety:it adopts infrared protection and airbag protection device.
Operating system: button, remote control, manual when power off



Product information for door

Opening Speed 0.7 ~ 1.2m/s
Interior / Exterior Door Suitable
Wind Bar Without or With, Accordingly to door model and size
Max Width 9500mm
Min/Max H 600 / 9500mm
Door Curtain Thickness 0.8mm / 1.2mm / 2.0mm
Drive Unit Electric / IP55
Safety Sensor Electric safety edge
Safety photovell
Control voltage 24V DC
Motor Brand SEW German
Nord German
Tube motor Taiwan
SEJ China
Servo System China
Control Brand Mitsubishi Japan
Servo China
Holip China
Command System Remote control, Radar sensor, Floor sensor, Rope switch, Key cards etc


Why Choose Us?

Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.

Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.





F A Q :


1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
