Dust Proof 220V 45mm Reinforce Girder Metal Security Shutters

China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
China Dongguan Hengtaichang Intelligent Door Control Technology Co., Ltd. certification
I'm Online Chat Now

Dust Proof 220V 45mm Reinforce Girder Metal Security Shutters

Dust Proof 220V 45mm Reinforce Girder Metal Security Shutters
Dust Proof 220V 45mm Reinforce Girder Metal Security Shutters
video play

Large Image :  Dust Proof 220V 45mm Reinforce Girder Metal Security Shutters

Product Details:
Place of Origin: China
Brand Name: Wuzuan
Model Number: PHSD-00019
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Packaging Details: wood case or strong paper carton
Delivery Time: 7-15days
Payment Terms: L/C, Western Union, MoneyGram
Supply Ability: 300pcs per month
Detailed Product Description
Material: PVC Fabric Door Frame Material: Stainless Steel / Aluminum Alloy / Power Coated Steel
Color: Blue, Black, WHITE, RED, Yellow, Orange, SKY BLUE, Light Grey Or Customized Pecial Door Type: Automatic Door
Open Style: Rolling Opening Speed: 0.7~1.2m/S
Curtain Thickness: 0.8mm/1.5mm Opening Style: Automatic & Manual
Operation Way: Push Button / Sensor / Radar / Pull Switch Opening Frequency: 1000-1500times/Day
Opening Type: Power Driven Special Function: Dust Proof, Security
Motor: 1.German Sew 2.China Sej / Snma Or Customized Motor Power: 0.75-5.5kw
Standard Motor Position: Left Or Right Application: Mall, Supermarket, Warehouse, Workshop
Type: Entry Doors,Garage Doors,Security Doors,Sliding Doors,industrial Door Size: Customized Size, According To Clients' Specification
Wind Resistence: 25m/S Specification: Maximun Size 6m*6m
Working Temperature: -35 To 65 Celsius Degree Installation Area: Exterior Or Interior
Safety Class: IP55 Emergency Operation: Available With Manual Crank
Operating Life: 50,000 Cycles Operation Switch: Button Switch, Radar Sensor, Magnetic Loop
High Light:

220V Metal Security Shutters

,

45mm Reinforce Girder Metal Security Shutters

,

45mm Reinforce Girder security roller doors

Dust Proof Industrial Automatic PVC Fabric High Speed Rolling up Door



High speed PVC Roller shutter door, used in high-frequency logistics channel. The door curtain wind resistant
pole was formed by the wind resistant steel tube( wind resistant pole: it is on the request about the door
opening's wind pressure to deploy), strong wind resistant, suitable for large-scale external doors and in
request wind resistant's internal doors, sealing, vermins-proof and dust-proof, protecting the working environment.


Applications:
Indoor, outdoor which requests resistant the wind/ temperature .
Heavy industry, Light industry, food industry, electronics, pharmaceutical, warehousing, packaging, printing, chemical industry, automobile, manufacturing.
The Industries In high request in environmental health.


Features:
Door leaf1.0mm 304 stainless steel or galvanized steel sheet materials with high-quality powder coating finish. Inside is filled with high-density paper honeycomb or Aluminium honeycomb.Door frame1.5mm galvanized steel or 1.0mm thick 304stainless steel.Vision windowspecial clean room glass. It is made from double layer tempered glass, and Its surface is on the same plane with door leaf, to avoid dust retention and realize easy cleaning.hinge304 stainless steel.lockstainless steel handle lock, beautiful and durable.
Seal structure3mm EPDM seal rubber is installed all-round the edge of the door frame to resist dust and rain. Further more, automatic seal rubber is installed at the bottom of the door leaf. It will automatically get down and close the gap with ground floor when door closed.



Product Details:



Rapid PVC Door Grey,Yellow grid,Purple,Green,Light green,Black,Perforated Yellow grid,White,Blue,White grid,Sky Blue,Yellow,Orange,Red
Color curtain:0.8mmthickness.
Transparent curtain:1.2mm.
Function:insect prevention
Reinforce Girder Aluminum alloy:45mm width.
Function:reinforce the curtain and wind resistant
Bottom Bar Aluminum alloy 95mm width
Function:reinforce the crutain to keep the door opening without a hitch
Radar Sensor The place on the cover box. Can detect 3 meters area!
Function: detect the moving thing and open the door.
For the place which has more people through.
Photocell Sensor Function:It's stop the door when the door is closing and someone through the door.
Drive System

High speed door motor:
380V/220V/110V, 50Hz/60Hz, 0.75KW,1.5KW,2.2kw.

Control System Control box:Include control system+PLC+transducer+encoder+airbag system.
Function: all the control system are inside in it.
Cover Box Material: Stainless steel201#or304#
To avoid corrosive thing corrode the roll and dustproof
Opening Way Radar sensor+push button for People through

Magnetic loop+push button for forklift through





Why Choose Us?

Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.

Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.





F A Q :


1,Are you trading company or manufacturer ?

A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
