Aluminum Spiral High Speed Rolling Door Panel Spiral Steel Rolling Shutter Door For Warehouse
The spiral door panel adopts the new anti-pinch broken bridge foaming technology, which makes the door body light and easy to install. It has improved in heat preservation and operation.
The running track can be single spiral, double spiral, elliptical, smooth, straight, and special-shaped series. The track can be designed according to the size of your door opening space. The motor can be built-in coaxial and side-mounted.Factory direct steel industrial sliding door manufacturer manual manufacturer
Aluminum Spiral High Speed Rolling Door panel Spiral Steel Rolling Shutter Door panel technology is an upgrade of the hard fast door plate. The traditionapiral l door panel encounters debris or hail will be caught in the link gap, resulting in door panel damage, deformation, abnormal sound and so on.
In the environment of high cold or large indoor and outdoor temperature difference, the traditional door panel is caused by the cold bridge leading to ice or frost. The new anti-pinch broken bridge foam door is the best solution, which greatly improves overall life of the door.
The opening mode is divided into Bluetooth, geomagnetic, swipe, radar, fingerprint password, manual button and so on. At the same time, it is equipped with anti-blocking light, infrared photoelectric, airbag, window and other security systems.
The width of the door panel is divided into 200 type and 220 type. The standard thickness is 43mm. It can be made into thickness of 50mm/75mm/100mm according to customer's requirements. The maximum opening width of the door is 12 meters, the maximum opening height is 8 meters, and the maximum opening frequency is 3000 times per day.
Widely used in industrial plants, cold chain, logistics, cold storage, fast track, automotive assembly, food processing, precision machinery, automotive 4s shop, underground parking lot, etc.
1, High Quality Materia
Carefully select material,using 1.2mm / 1.5mm / 2.0mm aluminum alloy plate which ensure this door meet customer's request.
2,Aperture Diaphragm Design
This kind of safety device is built into frame, it will feel object within it area.It will stop instantly when someone go through the door
3,Hot insulation Material Stuffing
The door panel is filled up with hot insulation material PU
4,Fast and Noiseless
With spiral round non-contact track,this sectional curtain will connect each other when door roll up,the curtain material won't wear out and distort,it runfast without noise
The panel is built into sealing which don't allow the air water,dust pest or other contaminants go into space after the door is shutter
|High Speed Spiral Door
|Max. opening speed
|Max. closing speed
|Emergency opening and emergency closing
|Hand chain with spring compensation support
||0.8mm aluminum alloy with PU-foamed
||galvanized steel frame
|Resistance to wind load
||UD=1.95W/(M²K) FOR 25M² door size
Why Choose Us?
Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.
Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
F A Q :
1,Are you trading company or manufacturer ?
A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your request.
