Product Details:
Payment & Shipping Terms:
|
| Material: | PVC Fabric | Door Frame Material: | Stainless Steel / Aluminum Alloy / Power Coated Steel |
|---|---|---|---|
| Color: | Blue, Black, WHITE, RED, Yellow, Orange, SKY BLUE, Light Grey Or Customized | Pecial Door Type: | Automatic Door |
| Open Style: | Rolling | Opening Speed: | 0.7~1.2m/S |
| Curtain Thickness: | 0.8mm/1.5mm | Opening Style: | Automatic & Manual |
| Operation Way: | Push Button / Sensor / Radar / Pull Switch | Opening Frequency: | 1000-1500times/Day |
| Opening Type: | Power Driven | Special Function: | Dust Proof, Security |
| Motor: | 1.German Sew 2.China Sej / Snma Or Customized | Motor Power: | 0.75-5.5kw |
| Standard Motor Position: | Left Or Right | Application: | Mall, Supermarket, Warehouse, Workshop |
| Type: | Entry Doors,Garage Doors,Security Doors,Sliding Doors,industrial Door | Size: | Customized Size, According To Clients' Specification |
| Wind Resistence: | 25m/S | Specification: | Maximun Size 6m*6m |
| Working Temperature: | -35 To 65 Celsius Degree | Installation Area: | Exterior Or Interior |
| Safety Class: | IP55 | Emergency Operation: | Available With Manual Crank |
| Operating Life: | 50,000 Cycles | Operation Switch: | Button Switch, Radar Sensor, Magnetic Loop |
| High Light: | 0.8mm Curtain PVC Roller Shutter Doors,1.2m/S PVC Roller Shutter Doors,1.2m/S PVC high speed door |
||
PVC high speed doors are designed for fast open and close, allowing people and/or equipment to move quickly through the opening. This type of doors is ideal for large size opening and designed for high performance daily use both internally and externally with minimal maintenance. The door operated as speed > 1m/s, this model doors offers beneficial energy saving in both commercial and industrial application. In additional it reduces noise and dust from nearby working areas. It was ideally choice for many commercial and industrial application.
Features:
1: Multifunctional: It has the functions of heat preservation, insect prevention, noise reduction, deodorization, indoor barrier function, reducing energy consumption and keeping the indoor working environment clean.
2: Strong sealing performance: The composite guide plate can be fully closed with the door frame under wind pressure. The bottom of the door frame is equipped with a weighted partition, which can be closely attached to the uneven ground to ensure its leakproofness.
3: Multiple designs: the size can be adjusted according to the size of the installation site, and windows can be added to increase indoor lighting and transparency.
4: Safety: Use infrared protection and airbag protection devices.
Operating system: buttons, remote control, manual when the power is off.
12. Optional control mode:Loop Sensor, Radar, Remote control, Linkage interlock, Pull rope, etc..
| Control System | DFL PLC / Holip PLCand other components. | ||
| Dynamical Systems | Motor: SEW or Nord from Germany Factory.(China unit: Powever/SERVO system) | ||
| Most stable brake system or Advanced Servo System, 220V~380V/50 -60HZ | |||
| Power: 0.75kw ~ 3.0kw(According to the size of door) | |||
| Fast Speed Gate Construction | |||
| Framework | In 2mm thickness cold-roll steel sheet or on request in Stainless steel INOX201/304, Plaint color accordingly to your order | ||
| Rolling Drum | 2mm thickness steel/Galvanized rube with machined blacks at each side and incorporating high-speed bearing. | ||
| Cross Bar | Normal in aluminum rod for small doors. Additional with Steel pipe for large opening and high-wind application. | ||
| Color | Red/Yellow/Blue/Sky blue/Orange/Mesh white and yellow/White/Green/Black/Grey. | ||
| Transparent Window | Transparent pvc sheet 1.5mm thickness. Window sizes and loaction accordingly to your requirement. | ||
| Command System | Magnetic Loop/Radar Sensor/Rope switch/Remote Control/Finger printer/Bluetooth/Key card etc. | ||
| Safety System & Seal | |||
| Photocell Sensor | Installed ont he side track with emergency rebound opening when sensing obstacles. | ||
| Safety edge bottom | When the people or vehicle touch the bottom edge of closing doors, It bound up automaticlly. | ||
| Emergency stop protection | With emergency stop button on the main control board. | ||
| Seal | Seal brush are installed inside of guider rail. Besides there is trap heavier fabric on the bottom, Close to any uneven ground. | ||
| Technical Parameter | Power Supply: Single or Three phase 220V~260V.. Three phase 380V~460V. 50/60HZ. | ||
| Max Size: 10m width * 15m height | |||
| Opening & Colsing speed: 0.7~1.5m/S | |||
| Operation Frequency: 1000~1500 Cycles/Day | |||
| Wind load: 15m/S | |||
Why Choose Us?
Over the years, our company has been working with the well-known manufacturers work closely with gated, has introduced the latest and most sophisticated production equipment of various volumes gate. The use of superior Quality raw materials and high-quality components, and adhere to the " excellence, precision production" product concept, to ensure the production of a variety of beautiful rolling door products Generous, easy operation, security, security, durability, quality assurance. We spirit of "honesty, quality first, customer first, service leader," the case Purpose, passion for the community to provide the safest customers the best a variety of roll gates, but also provide comprehensive maintenance service.
Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
